Parameter | Value |
---|---|
Length | 14 mm |
Termination | Crimp |
Max Operating Temperature | 125 °C |
Min Operating Temperature | -40 °C |
Height | 3.8 mm |
Depth | 5.4 mm |
REACH SVHC | No SVHC |
Contact Plating | Tin |
Contact Material(Contact Finish) | Bronze |
Current Rating | 5 A |
Orientation | Straight |
Lifecycle Status | Production (Last Updated: 2 weeks ago) |
Gender | Female |
Shielding | Unshielded |
ELV | Compliant |
Connector Type | Connector, PCB, Receptacle, Signal |
Wire/Cable Gauge | 20 AWG |
Wire Gauge (Max) | 24 AWG |
Wire Gauge (Min) | 20 AWG |
Insulation Diameter | 2.0066 mm |
Mating Tab Width | 990.6 µm |
Manufacturer Lifecycle Status | ACTIVE (Last Updated: 2 weeks ago) |
Sealable | No |
Packaging | Reel |
RoHS | Compliant |
Accessory Type | Series Receptacle Contact |
Stock: 9270
Distributors
pcbx
Unit Price$0.44130
Ext.Price$0.44130
Qty | Unit Price | Ext.Price |
---|---|---|
1 | $0.44130 | $0.44130 |
10 | $0.22065 | $2.20650 |
50 | $0.16973 | $8.48650 |
100 | $0.13056 | $13.05600 |
500 | $0.10043 | $50.21500 |
1000 | $0.07725 | $77.25000 |
3000 | $0.05942 | $178.26000 |
5000 | $0.05942 | $297.10000 |
10000 | $0.05386 | $538.60000 |
30000 | $0.05096 | $1528.80000 |
50000 | $0.04822 | $2411.00000 |
